Mechanical EU applicator (40mm stroke )
Moulds&Accessory
Technical Data
|
Model |
EW-09H029 |
|
Feed type |
Mechanical |
|
Press stroke |
40 mm |
|
Cross section range |
0.08 - 10 mm² (28 - 7 AWG) |
|
Crimp height adjustment |
Increment: 0.025 mm Max.: 2.0 mm |
|
Terminal pitch range |
Min.: 1 mm (0.04") |
|
Terminal thickness |
< 1,2mm (<0,047")) |
|
Weight |
3.9kg (8,6 lbs.) |
|
Base design |
3-point base clamp with male T-shaped ram adapter |
Feature
1.Mechanical Side feed or Rear feed..
2.Wire section between 0 and 10mm2.
3.Easy replacement of crimpers and anvils.
Application Range
More Info
Model：Mechanical EU applicator (40mm stroke )
Model：EW-09H029
Feed type：Mechanical
Press stroke：40 mm
Cross section range：0.08 - 10 mm² (28 - 7 AWG)
Crimp height adjustment Increment: 0.025 mm
Max.: 2.0 mm
Terminal pitch range：Min.: 1 mm (0.04")
Max.: 28 mm (1.10")
Feed type：Mechanical
Press stroke：40 mm
Cross section range：0.08 - 10 mm² (28 - 7 AWG)
Crimp height adjustment Increment: 0.025 mm
Max.: 2.0 mm
Terminal pitch range：Min.: 1 mm (0.04")
Max.: 28 mm (1.10")
