One meter stroke continuous tape wrapping machine
Tape Bundling
8
Model：One meter stroke continuous tape wrapping machine
Model:EW-1830
Input power:220V/110V
Applicable OD:2-15mm
Tape width:5-25mm
Rotator speed Up to 600 rpm
Pulling speed:0.5 m/s
Input power:220V/110V
Applicable OD:2-15mm
Tape width:5-25mm
Rotator speed Up to 600 rpm
Pulling speed:0.5 m/s
Technical Data
|
Model |
EW-1830 |
|
Input power |
220V/110V |
|
Applicable OD |
2-15mm |
|
Tape width |
5-25mm |
|
Tape material |
PVC, felt tape, cloth-based tape, high-temperature insulation tape, conductive tape, etc. |
|
Wrapping stroke |
Up to 1 meter |
|
Rotator speed |
Up to 600 rpm |
|
Pulling speed |
0.5 m/s |
|
Dimension |
1050*300*250mm |
|
Wrapping effect |
Flower wrapping and continuous wrapping, the overlapping part of the tape is adjustable |
|
Air source |
N/A, pure electric |
|
Pedal Start |
Yes |
Feature
1.PLC touch screen control panel,Clear operation interface, intelligent display, simple operation
2.Simple operation, stable performance,Wire harness slot, foot start, convenient use of various products
3.Multiple winding methods: you can set the winding mode to bifurcation, flower winding, full winding, and winding with different spacing.
4.Small size and light weight,The machine adopts pure electric design and is compact and practical.
Application Range
