Material width: 1 - 140 mm
Cutting length: 1 - 9999 mm
Cutting length increment: 1 mm
Cutting length tolerance: 0.1 mm
Cutting temperature: up to 400 ℃
● Specific hot cutting mode designed for cutting various fabrics, and the cutting width can be customized.
● Equipped with material rest, on which the material can be placed to ensure the steady feeding and cutting process.
● Equipped with feeding strips. The gap between the strips can be adjusted according to the material width, which also allows more production lines.
● SKD-11 material is selected as the balde material, and the average lifetime is up to 18 months.
Contact us for more details.
Model
EW-100RL
EW-160RL
Material width
1 - 80 mm
1 - 140 mm
Cutting length
1 - 9999 mm
1 - 9999 mm
Cutting length increment
1 mm
1 mm
Cutting length tolerance
0.1 mm
0.1 mm
Cutting temperature
Up to 400 ℃
Up to 400 ℃
Productivity
6000 - 7200 pcs./h (L = 50 mm)
6000 - 7200 pcs./h (L = 50 mm)
Motor
AC motor
AC motor
Display mode
LCD
LCD
Control mode
ARM processor
ARM processor
Power supply
110, 220 V (50 - 60 Hz)
110, 220 V (50 - 60 Hz)
Remarks
Cutting width can be customized
