Rated load：5000-30000N
Effective stroke：220 /1000mm
Test speed：15~240 mm/min
Electrical connection：AC 220/110V/50/60HZ
Features:
AEV electric vertical machine is a push -pull load test stand specially equipped for HF series and NK series force gauges. This product adopts dual vertical pole structure, featured by good stability, wide application and easy to use, etc., with the functions of stepless speed regulation, manual (crawl) and automatic switching. This product is appropriate for the push-pull load, plug power and other destructive tests in the industries of rubber, plastics, light textile, building doors and windows, composite materials, wire and cable, auto parts, power machinery and research institutions, etc.
a,Electric loading, stepless speed regulation, gear drive
b,Compact structure and stable drive
c,Simple operation, can be used with a variety of fixtures
Model
EW-25B
EW-25B-1
EW-25B-2
EW-25B-3
Rated load
500-5000N
1000-10000N
2000-20000N
3000-30000N
Test speed
60~220 mm/min
50~180 mm/min
50~180 mm/min
50~180 mm/min
Machine dimension:
400*250*1050mm
430*250*1160mm
430*250*1160mm
430*250*1160mm
Weight:
56KGS
65KGS
65KGS
65KGS
Effective stroke
220 /1000mm
Electrical connection
AC 220/110V/50/60HZ
