Model：Automatic Double Heads Plastic Shell Terminal Crimping and Twisting Machine

Scan the QR code

Share to:
    •
  • 刷新
Model:  EW-22D
Applicable  wire  size:  AWG14-AWG28
Cutting  length:  50-9999mm  (can  be  customized)
Stripping  and  twisting  length:  7-12mm
Crimping  force:  2T  (3T  is  optional)
Productivity:  1400pcs/h  (length<300mm)
ENQUIRE NOW!
Video Specifications

  • This is a fully automatic 2-ends wire cutting stripping and crimping machine for Plastic Shell Terminals. The highly flexible and electronically ontrolled benchtop unit accepts most universal or mini-style applicators for crimping both side-feed and rear-feed open barrel terminals. You can also save you settings in a program file number, so that you can call it out easily next time.

  • Model

    EW-22D

    Applicable wire range

    AWG28-AWG14

    Stripping/Twisting length

    7-12mm

    Cut precision

    ±(0.5+0.002*L) mm, L=cut length

    Cutting length

    50-9999mm

    Capacity

    1400pcs/hour(Length less than 300mm)

    Crimping force

    2.0T

    Applicators

    30mm or 40mm strokes for optional

    Air pressure

    4-6KGF

    Detection

    Wire run out, low air pressure, terminate error(Crimping force monitor is for optional)

    Power

    220V/110V/50/60HZ

    Display language

    Chinese/English

    Dimension

    700*800*1500mm

    Weight

    358Kg

    Power cord plug

    European, USA, Chinese plug
