Model：15T Precision Servo Terminal Crimping Machine
Scan the QR code
Model:EW-5070
Crimping stroke：60mm
Crimping range：6-120mm2
Crimping precision：±0.03 mm
Crimping capability：15T
Crimping stroke：60mm
Crimping range：6-120mm2
Crimping precision：±0.03 mm
Crimping capability：15T
1. Support various industrial protocols Modbus and OPC cloud protocol analysis.
2. The motor is built in, the desktop body is convenient to move.
3. Work smoothly, have large output, and have overload protection function.
4. The protective cover can effectively protect the safety of personnel.
(The protective cover is not universal because the mold crimping position is not used)
Model
EW-5070-1
EW-5070-2
Power Supply
AC 110/220V 50/60Hz
AC 110/220V 50/60Hz
Crimping stroke
60mm
60mm
Crimping range
6-120mm2
10-240mm2
Crimping precision
±0.03 mm
±0.03 mm
Crimping capability
15T
30T
Drive mode
Driven by servo
Driven by servo
Dimension
L767*W612*H158 mm
L817*W612*H158 mm
Weight
300KG
310KG
