Model：Linear Feed Tape Wrapping Machine（0.1 - 30 mm OD)
Scan the QR code
Model: EW-AT-301P
Applicable tape material: wide range of industrial tapes
Application: sport wrap, long wire wrap
Feed length: max. 1050 mm (can be customized)
Wrap outer diameter: 0.1 - 30 mm
Tape width: 5 - 25 mm (can be customized)
Tape inner diameter: 38/32 mm (can be customized)
Tape outer diameter:< 110 mm
Applicable tape material: wide range of industrial tapes
Application: sport wrap, long wire wrap
Feed length: max. 1050 mm (can be customized)
Wrap outer diameter: 0.1 - 30 mm
Tape width: 5 - 25 mm (can be customized)
Tape inner diameter: 38/32 mm (can be customized)
Tape outer diameter:< 110 mm
The EW-AT-301P is a linear feed tape wrap machine with maximum 1050 mm feed length.
● Spot wrap; long wire wrap.
● Applicable for wide range of industrial tapes.
● Customization possibilities for special requirements.
Model
EW-AT-301P
Applicable tape material
Wide range of industrial tapes
Application
Sport wrap, long wire wrap
Feed length
Max. 1050 mm (can be customized)
Wrap outer diameter
3 - 25 mm (standard version)
0.1 - 3 mm (confirmed according to the material)
25 - 30 mm (confirmed according to the material)
Tape width
5 - 25 mm (can be customized)
Tape inner diameter
38/32 mm (can be customized)
Tape outer diameter
< 110 mm
Rotation speed
300 - 2500 rpm. (adjustable)
Power supply
110, 220 V (50 - 60 Hz)
Weight
40 kg
Dimension
1470 * 380 * 280 mm
