Tube Feeding Machine(Max. 30kg)
Prefeeding& Deposit System
Technical Data
|
Model |
EW-1715 |
|
Max. loading weight |
30kg |
|
Max. wire size |
40mm |
|
Cable drum OD |
800mm |
|
Cable drum ID |
250mm |
|
Cable drum width |
800 |
|
Motor power |
550W |
|
Machine size |
1400*700*1180mm |
|
G.W. |
850KG |
Feature
· Main frame material: high-quality carbon steel, firm structure and beautiful appearance.
· Induction method: multi-speed inverter, automatic adjustment according to the height of the wire storage wheel.
·Tension adjustment: adjust the tension by regulating the position of the counterweight.
Application Range
More Info
Model：Tube Feeding Machine(Max. 30kg)
Model EW-1715
Max. loading weight 30kg
Max. wire size 40mm
Cable drum OD 800mm
Cable drum ID 250mm
Cable drum width 800
Motor power 550W
Machine size 1400*700*1180mm
G.W. 850KG
Max. loading weight 30kg
Max. wire size 40mm
Cable drum OD 800mm
Cable drum ID 250mm
Cable drum width 800
Motor power 550W
Machine size 1400*700*1180mm
G.W. 850KG
