Stripping capability 3-layer stripping for shield cable
Wire material Wide range of industrial wires
Conductor cross-section 1.5 - 95 mm² (22 mm OD)
Cutting length 1 - 100,000 mm
The EW-05D-1 cutting and stripping machine processes wires with a cross section of 1.5 to 95 mm² with maximized productivity up to 1200 pcs./h!
1. 12-roller driving with belts feeding. Strong feeding force, highly precise feed length as per program set with 0.1 mm increment and no scratch mark on wire insulation/jacket guarantee, which is widely applied in defense industry, medical industry, information and communication technology (ICT) industry etc.
2. Programmable and intuitive roller gap and roller pressure setup on PLC touch screen, no need manual adjustment.
3. Longer left side stripping length (max.320 mm), thanks to the auto-open function of left roller set.
4. Memory capacity of 100 programs with specific 3-layer stripping program for shield cable.
5. Optional middle strip module, slit module.
6. Optional pre-feeder, stacker and coiler.
Model
EW-05D-1+C
Stripping capability
3-layer stripping for shield cable
Wire material
Wide range of industrial wires
Conductor cross-section
1.5 - 95 mm² (22 mm OD)
Cutting length
1 - 100,000 mm
Cutting length tolerance
< 0.002 * L
Stripping length (side I)
0 - 320 mm
Stripping length (side II)
0 - 160 mm
Slitting function
Optional
Maximum guide tube diameter
22 mm
Driving mode
12-roller with belts driving
Display mode
7-inch touch screen
Memory capacity
100 programs
Blade material
High speed steel
Productivity
800 - 1200 pcs./h
Power supply
110, 220 V (50 - 60 Hz)
Power
800 W
Weight
125 kg
Dimension
700 * 640 * 480 mm
Coiling inner diameter
120-250mm
Coiling outer diameter
400-600mm
Coiling driven
Servo motor, coil speed adjust according to strip machine
