Sevo Motor Crimping Machine 2.5-300mm2
Electrical
Technical Data
|
Product Name |
10T Servo Terminal Machine |
20T Servo Terminal Machine |
30T Servo Terminal Machine |
40T Servo Terminal Machine |
50T Servo Terminal Machine |
|
Model |
EW-5390-10T |
EW-5390-20T |
EW-5390-30T |
EW-5390-40T |
EW-5390-50T |
|
Stroke |
40MM |
50MM |
50MM |
70MM |
70MM |
|
Crimp Range |
2.5-35mm2 |
2.5-95mm2 |
2.5-180mm2 |
2.5-200mm2 |
2.5-300mm2 |
|
Crimp accurate |
0.03MM |
±0.03MM |
±0.03MM |
±0.03MM |
±0.03MM |
|
Machine size |
540*350*785 |
560X400X985 |
560X400X985 |
700X480X1225 |
700X480X1225 |
|
Machine weight |
230KG |
450KG |
450KG |
670KG |
670KG |
|
Power |
1.5KW |
2.6KW 10NM |
2KW 15NM |
3KW 15NM |
3KW 18NM |
|
Starting Mode |
|
Touch display/Foot switch |
|||
Feature
· Crimping precision control: 1μm optical encoder;
· Can be connected to the scan code gun, to achieve ERP management system docking
· Store past crimping data for quality management tracking
· The formula database can be established according to the product
· Quickly switch between different terminal heights
· Can connection to EMS system (optional computer version)
Application Range
More Info
Model：Sevo Motor Crimping Machine 2.5-300mm2
Model： EW-5390
Crimp range :2.5-35mm2/2.5-95mm2/2.5-180mm2/2.5-200mm2/2.5-300mm2
Stroke：40/50/70mm
Motor :Servo
Crimp range :2.5-35mm2/2.5-95mm2/2.5-180mm2/2.5-200mm2/2.5-300mm2
Stroke：40/50/70mm
Motor :Servo
