2. Conductor cross-section: 2.5 - 120 mm²
3. Cutting length: 1 - 99999.99 mm
4. Cutting length tolerance: ± 0.002 * L
5. Stripping length (side I): 1 - 300 mm
6. Stripping length (side II): 1 - 150 mm
The EW-05H+C is designed for processing wide range of industrial multi-conductor cable up to 120 mm².
● Full-strip; half-strip.
● User-friendly production setup.
● Memory capacity of 100 materials.
● Equipped material detection sensor and safety guard sensor.
● Optional all servomotor version with 20 % increased productivity.
● Custom possibility for special applications.
EW-05H
EW-05H+
Conductor cross-section
2.5 - 120 mm²
2.5 - 120 mm²
Core wire stripping
N/A
2 - 10 cores
Cutting length
1 - 99999.9 mm
1 - 99999.9 mm
Cutting length tolerance
< 0.002 * L (L = cutting length)
< 0.002 * L (L = cutting length)
Stripping length (side I)
- Full strip: 1 - 300 mm
- Half strip: 1 - 1000 mm
Cable jacket
- Full strip: 20 - 250 mm
Core wire
- Full strip: 1 - 50 mm
Stripping length (side II)
- Full strip: 1 - 150 mm
- Half strip: 1 - 500 mm
Cable jacket
- Full strip: 20 - 200 mm
Core wire
- Full strip: 1 - 50 mm
Maximum guide tube diameter
30 mm
27mm
Productivity
2000 pcs./h
2000 pcs./h
Blade material
Imported high speed steel
Imported high speed steel
Display mode
7-inch touch screen
7-inch touch screen
Driving mode
24-wheel driving, servo tool holder
24-wheel driving, servo tool holder
Feeding mode
By belts
By belts
Power supply
110, 220 V (50 - 60 Hz)
110, 220 V (50 - 60 Hz)
Power
2.25 kW
1.85 kW
Compressed air connection
0.5 - 0.7 MPa
0.5 - 0.7 MPa
Weight
260 kg
260 kg
Dimension
1020 * 590 * 1140 mm
1020 * 590 * 1140 mm
Remarks
Custom options in accordance with samples
