Electric Cable Wire Brushing and Twisting Machine(0.1-2mm2)
Shield Process
808
Model：Electric Cable Wire Brushing and Twisting Machine(0.1-2mm2)
Model:EW-10WT-1
Air pressure:1.5-2.5kg/C㎡
Speed:1400 RPS
Twisting length:5-80 mm
Twisting range:0.1-2mm2
Air pressure:1.5-2.5kg/C㎡
Speed:1400 RPS
Twisting length:5-80 mm
Twisting range:0.1-2mm2
Technical Data
|
Model |
EW-10WT-1 |
|
Stripping length |
5—80mm (Can be customized to 150mm) |
|
Stripping range |
0.1-2mm2 |
|
Air Pressure |
1.5-2.5kg/cm2 |
|
Voltage |
220V/110V/50HZ/60HZ |
|
Motor Power |
10W / 1400RPS |
|
Weight |
12KGS |
|
Size |
L340*W220*H210mm |
Feature
Cable Shield Braid Twisting Machine is mainly used for twisting the outside braid of shielded cable.
● It can twist cable braid layer all-in-one and brushing cables.
● The speed is controllable. and the performance is stable.
● It is a common and necessary equipment for wire harness processing.
● It can be used for processing different kinds of ground cables, braided cables, shielded cables etc.
Application Range
