Cut&Strip
Wire Cutting & Stripping Machine (0.3 - 25 mm²)
Model：Wire Cutting & Stripping Machine (0.3 - 25 mm²)

Scan the QR code

Share to:
ENQUIRE NOW!
1. Model: EW-05C
2. Wire material: PVC, teflon, fiberglass wire...
3. Conductor cross-section: 0.3 - 25 mm²
4. Cutting length: 1 - 60,000 mm
5. Cutting length tolerance:< 0.002 * L
6. Stripping length (side I): 0 - 50 mm
7. Stripping length (side II): 0 - 50 mm
Video
Specifications
Model EW-05C
Wire material PVC,fiberglasswire etc.
Conductor cross-section 0.3 - 25 mm² (27 - 3 AWG)
Cutting length 1 - 99,999 mm
Cutting length tolerance <0.002 * L
Stripping length Side I: 0 - 50 mm
Side II: 0 - 50 mm
Maximum guide tube diameter 13 mm
Productivity 3000 - 4000 pcs./h (25 mm², L = 100 mm)
Noise level < 70 dB(A)
Power supply 110, 220 V (50 - 60 Hz)
Power 500 W
Weight 32 kg
Dimension 390 * 350 * 255 mm
